Call for price
| Specifications | Accuracy |
|---|---|
| Rated capacity(R.C) | 10, 20, 50, 100, 200kgf, 500kg (98.07N, 196.1N, 490.3N, 980.7N, 4.903kN) |
| Rated output(R.O) | 2mV/Vยฑ0.5% |
| Nonlinearity | 0.03% of R.O |
| Hysteresis | 0.02% of R.O. |
| Repeatability | 0.02% of R.O. |
| Zero balance | ยฑ1% of R.O. |
| Temperature effect, on rated output | 0.02% of LOAD/10โ |
| Temperature effect, on zzero balance | 0.02% of R.O./10โ |
| Temperature range, compensated | -10~70โ |
| Temperature range, safe | -20~80โ |
| Terminal resistance input | 350ยฑ50ฮฉ |
| Terminal resistance output | 350ยฑ5ฮฉ |
| Insulation resistance bridge | 2000Mฮฉ |
| Excitation recommended | 10V |
| Safe overload | 150% R.C. |
| Cable length | ฮฆ5 4core cable, 3m |
| Capacity | A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | Weight(ใ) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10~100ใ(98.1~980.7N) | 130 | 10 | 72 | 35 | 13 | 39 | 20 | 9 | 42 | 8.5 | 8.5 | 20 | 58 | 17 | 35 | 1.0 |
| 200~500ใ(1.9~4.90KN) | 200 | 20 | 120 | 45 | 15 | 50 | 29 | 14 | 52 | 12 | 14 | 40 | 80 | 25 | 40 | 1.8 |
| model | SL15, SL30, SL50, SL100, SL300, SL500, SL1000 |
|---|
