Brand: Dacell
Categories: Indicators & Controllers
Call for price
Call for price
Tags: Petrascale
| SPECIFICATIONS | |
| Temperature storage | -10℃ ~ 85℃ |
| Temperature operating | 0 ~ 60℃ |
| Relat output | AC 125V 0.5A, DC 24V 1A |
| Transducer excitation | 5, 10, 15, 24VDC, ±15VDC |
| Type of inputs accepted | 0.5 ~ 3.5mV/V |
| Transducer current drive | 120mA |
| Calibration method | Front panel switches |
| Frequency response | 5KHz |
| Full scale output | 0~5V, 10V |
| Low pass filter | 10Hz, 100Hz, 1KHz |
| Temperature drift | 0.02% FS/ËšC |
| A/D conversion | 16Bit |
| Sampling speed | 500times/sec |
| Characters displayed | 5 digits |
| Typical accuracy | ±0.02% |
| Polarity indicator | Yes |
| Decimal point selection | Push button setup |
| Display size | 14mm & 10mm |
| Resolution maximum | 99999 |
| Type | 5X7 DOT 20Digit 4Line |
| Input/output connector | Push button |
| Weight | 1000g |
| Mounting | Panel mounting |
| Size | 96mm × 96mm × 166mm |
| Power requirements | 220V : 50/60Hz(Option 110VAC, DC24V) |
