Brand: EOSLIFT
Categories: Electric Light-Duty Counterbalance
Call for price
| Product Specifications | ||||
|---|---|---|---|---|
| Model | CPDS10 | CPDS15 | ||
| Power Type | Battery | Battery | ||
| Operation Type | Seated | Seated | ||
| Rated Capacity | 2204.62 lbs.. | 3306.93 lbs. | ||
| Load Center | 19.68 in. | 19.68 in. | ||
| Wheelbase | 38.38~38.97~40.15 in. | 44.37~44.96~46.14 in. | ||
| Service Weight (inc. battery) | 3747.85 lbs. | 4387.19 lbs. | ||
Brand: EOSLIFT
Categories: Electric Light-Duty Counterbalance
Call for price
| Product Specifications | ||||
|---|---|---|---|---|
| Model | CPDS10 | CPDS15 | ||
| Power Type | Battery | Battery | ||
| Operation Type | Seated | Seated | ||
| Rated Capacity | 2204.62 lbs.. | 3306.93 lbs. | ||
| Load Center | 19.68 in. | 19.68 in. | ||
| Wheelbase | 38.38~38.97~40.15 in. | 44.37~44.96~46.14 in. | ||
| Service Weight (inc. battery) | 3747.85 lbs. | 4387.19 lbs. | ||
Tags: Eoslift Brand, Eoslift Limited, non-reviewed
| Wheels Chassis | ||||
|---|---|---|---|---|
| Wheel Type | PU | PU | ||
| Load Wheel | 11.22 x 3.93 in. | 11.22 x 3.93 in. | ||
| Drive Wheel | 9.05 x 4.33 in. | 11.02 x 5.31 in. | ||
| Number of Wheels, front/rear (x=drive wheel) | – | – | ||
| Wheel Tread, load side | 31.65 in. | 31.65 in. | ||
| Dimensions | ||||
|---|---|---|---|---|
| Tilting | 2/4/ | 2/4/ | ||
| Mast Closed Height | 78.54 in. | 78.54 in. | ||
| Free Lift Height | 4.33 in. | 3.54 in. | ||
| Lift Height | 118.11 in. | 118.11 in. | ||
| Mast extended heightw/ load-backrest | 138.97 in. | 138,97 in. | ||
| Overall Length | 91.73 in. | 98.26 | ||
| Overall Width | 35.90 in. | 35.90 in. | ||
| Fork Size | 36.22/3.93/1.37 in.. | 36.22/3.93/1.37 in. | ||
| Fork Outside Width | 8.66~24.40 in. | 8.66~24.40 in. | ||
| Handle Height | – | – | ||
| Mast Ground Clearance | 3.54 in. | 3.54 in. | ||
| Aisle width for pallet 39.37 x 47.24 in. | 108.66 in. | 115.15 in. | ||
| Aisle width for pallet 31.49 x 47.24 in. | 112.99 in. | 119.56 in. | ||
| Turning Radius | 49.40 in. | 55.70 in. | ||
| Performance | ||||
|---|---|---|---|---|
| Driving Speed (load/unload) | 3.7/7 mph | 3.7/7 mph | ||
| Lifting Speed (load/unload) | 5.9/7.48 in/s | 4.33/7.87 in./s | ||
| Lowering Speed (load/unload) | 7.87/5.11 in./s | 5.51/5.51 in./s | ||
| Max. gradeability (load/unload) | 8/10 | 5/10 | ||
| Brake Type | Hydraulic+ Electromagnetic | Hydraulic+ Electromagnetic | ||
| Drive | ||||
|---|---|---|---|---|
| Driving Motor/Power (S2-60min) | 1.5 kw | 1.5 kw | ||
| Lifting Motor/Power (S3-15%) | 2 kw | 3 kw | ||
| Battery Voltage/Capacity | 24/300 V/Ah | 24/350 V/Ah | ||
| Battery Weight | 610.68 lbs. | 672.40 lbs. | ||
| Steering System | EPS | EPS | ||
Product features
Porduct features
