Brand: EOSLIFT
Categories: Aerial Work Platform
Call for price
Brand: EOSLIFT
Categories: Aerial Work Platform
Call for price
| Model | Lifting Capacity (Weight) | Lifting Height | Price |
|---|---|---|---|
| EDAG1590 | 150 kg | 9000mm | Call for price |
| EDAG2075 | 200 Kg | 7500mm | Call for price |
| General Information | ||||||
| Model | EDAG2075 | EDAG1590 | ||||
| Max. platform height | (mm) | 7500 | 9000 | |||
| Max. Working Height | (mm) | 9000 | 10500 | |||
| Ground clearance | (mm) | 20 | ||||
| Lift rated capacity | (kg) | 200 | 150 | |||
| Platform size | (mm) | 1000X700X1100 | ||||
| Driving speed(platform stowed) | (Km/h) | 3-4 | ||||
| Driving speed(platform elevated) | (Km/h) | 0.6-1 | ||||
| Max. climbing ability | % | 20 | ||||
| Battery | (V/Ah) | 2×12/150 | ||||
| Charger | (V/A) | 24/25 | ||||
| Pothole protection system | Mechanical control | |||||
| Lifting motor | (V/KW) | 24/2.2 | ||||
| Driving motor | (V/KW) | 2×24/0.5 | ||||
| Overall length | (mm) | 1700 | ||||
| Overall width | (mm) | 1000 | ||||
| Overall height | (mm) | 2000 | 2100 | |||
| Net weight | (kg) | 1100 | 1250 | |||
